Appendix
A.9 Information List
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
456
403 >Idmd MIN/MAX Buffer Reset
(>Idmd MiMaReset)
Min/Max meter SP on * * LED BI BO
404 >Pdmd MIN/MAX Buffer Reset
(>Pdmd MiMaReset)
Min/Max meter SP on * * LED BI BO
405 >Qdmd MIN/MAX Buffer Reset
(>Qdmd MiMaReset)
Min/Max meter SP on * * LED BI BO
406 >Sdmd MIN/MAX Buffer Reset
(>Sdmd MiMaReset)
Min/Max meter SP on * * LED BI BO
407 >Frq. MIN/MAX Buffer Reset
(>Frq MiMa Reset)
Min/Max meter SP on * * LED BI BO
408 >Power Factor MIN/MAX Buffer
Reset (>PF MiMaReset)
Min/Max meter SP on * * LED BI BO
409 >BLOCK Op Counter (>BLOCK
Op Count)
Statistics SP On
Off
* LED BI BO
412 >Theta MIN/MAX Buffer Reset (>
Θ MiMa Reset)
Min/Max meter SP on * * LED BI BO
501 Relay PICKUP (Relay PICKUP) P.System Data 2 OUT ON m LED BO 150 151 2 Yes
502 Relay Drop Out (Relay Drop Out) Device, General SP * *
510 General CLOSE of relay (Relay
CLOSE)
Device, General SP * *
511 Relay GENERAL TRIP command
(Relay TRIP)
P.System Data 2 OUT ON m LED BO 150 161 2 Yes
533 Primary fault current Ia (Ia =) P.System Data 2 VI On
Off
150 177 4 No
534 Primary fault current Ib (Ib =) P.System Data 2 VI On
Off
150 178 4 No
535 Primary fault current Ic (Ic =) P.System Data 2 VI On
Off
150 179 4 No
545 Time from Pickup to drop out (PU
Time)
Device, General VI
546 Time from Pickup to TRIP (TRIP
Time)
Device, General VI
561 Manual close signal detected
(Man.Clos.Detect)
P.System Data 2 OUT On
Off
**LEDBO
916 Increment of active energy
(WpΔ=)
Energy -
917 Increment of reactive energy
(WqΔ=)
Energy -
1020 Counter of operating hours
(Op.Hours=)
Statistics VI
1021 Accumulation of interrupted
current Ph A (Σ Ia =)
Statistics VI
1022 Accumulation of interrupted
current Ph B (Σ Ib =)
Statistics VI
1023 Accumulation of interrupted
current Ph C (Σ Ic =)
Statistics VI
1201 >BLOCK 64 (>BLOCK 64) Sens. Gnd Fault SP On
Off
* * LED BI BO 151 101 1 Yes
1202 >BLOCK 50Ns-2 (>BLOCK
50Ns-2)
Sens. Gnd Fault SP On
Off
* * LED BI BO 151 102 1 Yes
1203 >BLOCK 50Ns-1 (>BLOCK
50Ns-1)
Sens. Gnd Fault SP On
Off
* * LED BI BO 151 103 1 Yes
1204 >BLOCK 51Ns (>BLOCK 51Ns) Sens. Gnd Fault SP On
Off
* * LED BI BO 151 104 1 Yes
1207 >BLOCK 50Ns/67Ns (>BLK
50Ns/67Ns)
Sens. Gnd Fault SP On
Off
* * LED BI BO 151 107 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
To Next Page
