Appendix
A.9 Information List
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
462
5166 46-TOC picked up (46-TOC
pickedup)
46 Negative Seq OUT * On
Off
* LED BO 70 141 2 Yes
5170 46 TRIP (46 TRIP) 46 Negative Seq OUT * on m LED BO 70 149 2 Yes
5171 46 Disk emulation picked up (46
Dsk pickedup)
46 Negative Seq OUT * * * LED BO
5203 >BLOCK 81O/U (>BLOCK
81O/U)
81 O/U Freq. SP On
Off
* * LED BI BO 70 176 1 Yes
5206 >BLOCK 81-1 (>BLOCK 81-1) 81 O/U Freq. SP On
Off
* * LED BI BO 70 177 1 Yes
5207 >BLOCK 81-2 (>BLOCK 81-2) 81 O/U Freq. SP On
Off
* * LED BI BO 70 178 1 Yes
5208 >BLOCK 81-3 (>BLOCK 81-3) 81 O/U Freq. SP On
Off
* * LED BI BO 70 179 1 Yes
5209 >BLOCK 81-4 (>BLOCK 81-4) 81 O/U Freq. SP On
Off
* * LED BI BO 70 180 1 Yes
5211 81 OFF (81 OFF) 81 O/U Freq. OUT On
Off
* * LED BO 70 181 1 Yes
5212 81 BLOCKED (81 BLOCKED) 81 O/U Freq. OUT On
Off
On
Off
* LED BO 70 182 1 Yes
5213 81 ACTIVE (81 ACTIVE) 81 O/U Freq. OUT On
Off
* * LED BO 70 183 1 Yes
5214 81 Under Voltage Block (81
Under V Blk)
81 O/U Freq. OUT On
Off
On
Off
* LED BO 70 184 1 Yes
5232 81-1 picked up (81-1 picked up) 81 O/U Freq. OUT * On
Off
* LED BO 70 230 2 Yes
5233 81-2 picked up (81-2 picked up) 81 O/U Freq. OUT * On
Off
* LED BO 70 231 2 Yes
5234 81-3 picked up (81-3 picked up) 81 O/U Freq. OUT * On
Off
* LED BO 70 232 2 Yes
5235 81-4 picked up (81-4 picked up) 81 O/U Freq. OUT * On
Off
* LED BO 70 233 2 Yes
5236 81-1 TRIP (81-1 TRIP) 81 O/U Freq. OUT * on m LED BO 70 234 2 Yes
5237 81-2 TRIP (81-2 TRIP) 81 O/U Freq. OUT * on m LED BO 70 235 2 Yes
5238 81-3 TRIP (81-3 TRIP) 81 O/U Freq. OUT * on m LED BO 70 236 2 Yes
5239 81-4 TRIP (81-4 TRIP) 81 O/U Freq. OUT * on m LED BO 70 237 2 Yes
6503 >BLOCK 27 undervoltage pro-
tection (>BLOCK 27)
27/59 O/U Volt. SP * * * LED BI BO 74 3 1 Yes
6505 >27-Switch current supervision
ON (>27 I SUPRVSN)
27/59 O/U Volt. SP On
Off
**LEDBIBO7451Yes
6506 >BLOCK 27-1 Undervoltage pro-
tection (>BLOCK 27-1)
27/59 O/U Volt. SP On
Off
**LEDBIBO7461Yes
6508 >BLOCK 27-2 Undervoltage pro-
tection (>BLOCK 27-2)
27/59 O/U Volt. SP On
Off
**LEDBIBO7481Yes
6509 >Failure: Feeder VT
(>FAIL:FEEDER VT)
Measurem.Superv SP On
Off
**LEDBIBO7491Yes
6510 >Failure: Busbar VT (>FAIL: BUS
VT)
Measurem.Superv SP On
Off
**LEDBIBO74101Yes
6513 >BLOCK 59 overvoltage protec-
tion (>BLOCK 59)
27/59 O/U Volt. SP * * * LED BI BO 74 13 1 Yes
6530 27 Undervoltage protection
switched OFF (27 OFF)
27/59 O/U Volt. OUT On
Off
**LEDBO74301Yes
6531 27 Undervoltage protection is
BLOCKED (27 BLOCKED)
27/59 O/U Volt. OUT On
Off
On
Off
* LED BO 74 31 1 Yes
6532 27 Undervoltage protection is
ACTIVE (27 ACTIVE)
27/59 O/U Volt. OUT On
Off
**LEDBO74321Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
