Siemens SIPROTEC 7SK80 User Manual

Appendix
A.9 Information List
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
463
6533 27-1 Undervoltage picked up
(27-1 picked up)
27/59 O/U Volt. OUT * On
Off
* LED BO 74 33 2 Yes
6534 27-1 Undervoltage PICKUP
w/curr. superv (27-1 PU CS)
27/59 O/U Volt. OUT * On
Off
* LED BO 74 34 2 Yes
6537 27-2 Undervoltage picked up
(27-2 picked up)
27/59 O/U Volt. OUT * On
Off
* LED BO 74 37 2 Yes
6538 27-2 Undervoltage PICKUP
w/curr. superv (27-2 PU CS)
27/59 O/U Volt. OUT * On
Off
* LED BO 74 38 2 Yes
6539 27-1 Undervoltage TRIP (27-1
TRIP)
27/59 O/U Volt. OUT * on m LED BO 74 39 2 Yes
6540 27-2 Undervoltage TRIP (27-2
TRIP)
27/59 O/U Volt. OUT * on * LED BO 74 40 2 Yes
6565 59-Overvoltage protection
switched OFF (59 OFF)
27/59 O/U Volt. OUT On
Off
**LEDBO74651Yes
6566 59-Overvoltage protection is
BLOCKED (59 BLOCKED)
27/59 O/U Volt. OUT On
Off
On
Off
* LED BO 74 66 1 Yes
6567 59-Overvoltage protection is
ACTIVE (59 ACTIVE)
27/59 O/U Volt. OUT On
Off
**LEDBO74671Yes
6568 59-1 Overvoltage V> picked up
(59-1 picked up)
27/59 O/U Volt. OUT * On
Off
* LED BO 74 68 2 Yes
6570 59-1 Overvoltage V> TRIP (59-1
TRIP)
27/59 O/U Volt. OUT * on m LED BO 74 70 2 Yes
6571 59-2 Overvoltage V>> picked up
(59-2 picked up)
27/59 O/U Volt. OUT * On
Off
* LED BO
6573 59-2 Overvoltage V>> TRIP (59-2
TRIP)
27/59 O/U Volt. OUT * on * LED BO
6801 >BLOCK 48 Motor Startup Time
Supervision (>BLOCK 48)
48/66/51M Motor SP * * * LED BI BO
6805 >48/14 Mot.St.Time Sup. Rotor
locked (>48 Rot. locked)
48/66/51M Motor SP * * * LED BI BO
6811 48 Motor Startup Time Supervi-
sion OFF (48 OFF)
48/66/51M Motor OUT On
Off
* * LED BO 169 51 1 Yes
6812 48 Motor Startup Time Superv.
BLOCKED (48 BLOCKED)
48/66/51M Motor OUT On
Off
On
Off
* LED BO 169 52 1 Yes
6813 48 Motor Startup Time Supervi-
sion ACTIVE (48 ACTIVE)
48/66/51M Motor OUT On
Off
* * LED BO 169 53 1 Yes
6821 48 Motor Startup Time Supervi-
sion TRIP (48 TRIP)
48/66/51M Motor OUT * on m LED BO 169 54 2 Yes
6822 48/14 Mot.St.Time Sup. Rotor
locked (48 Rotor locked)
48/66/51M Motor OUT * on * LED BO 169 55 2 Yes
6823 48 Motor Startup Time Superv.
picked up (48 pickup)
48/66/51M Motor OUT On
Off
* * LED BO 169 56 1 Yes
6851 >BLOCK 74TC (>BLOCK 74TC) 74TC TripCirc. SP * * * LED BI BO
6852 >74TC Trip circuit superv.: trip
relay (>74TC trip rel.)
74TC TripCirc. SP On
Off
* * LED BI BO 170 51 1 Yes
6853 >74TC Trip circuit superv.: bkr
relay (>74TC brk rel.)
74TC TripCirc. SP On
Off
* * LED BI BO 170 52 1 Yes
6861 74TC Trip circuit supervision OFF
(74TC OFF)
74TC TripCirc. OUT On
Off
* * LED BO 170 53 1 Yes
6862 74TC Trip circuit supervision is
BLOCKED (74TC BLOCKED)
74TC TripCirc. OUT On
Off
On
Off
* LED BO 153 16 1 Yes
6863 74TC Trip circuit supervision is
ACTIVE (74TC ACTIVE)
74TC TripCirc. OUT On
Off
* * LED BO 153 17 1 Yes
6864 74TC blocked. Bin. input is not
set (74TC ProgFail)
74TC TripCirc. OUT On
Off
* * LED BO 170 54 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
