Siemens SIPROTEC 7SK80 User Manual

Appendix
A.9 Information List
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
464
6865 74TC Failure Trip Circuit (74TC
Trip cir.)
74TC TripCirc. OUT On
Off
* * LED BO 170 55 1 Yes
7551 50-1 InRush picked up (50-1 In-
RushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 80 2 Yes
7552 50N-1 InRush picked up (50N-1
InRushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 81 2 Yes
7553 51 InRush picked up (51 InRush-
PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 82 2 Yes
7554 51N InRush picked up (51N In-
RushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 83 2 Yes
7556 InRush OFF (InRush OFF) 50/51 Overcur. OUT On
Off
**LEDBO60921Yes
7557 InRush BLOCKED (InRush BLK) 50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 93 1 Yes
7558 InRush Ground detected (InRush
Gnd Det)
50/51 Overcur. OUT * On
Off
* LED BO 60 94 2 Yes
7559 67-1 InRush picked up (67-1 In-
RushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 84 2 Yes
7560 67N-1 InRush picked up (67N-1
InRushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 85 2 Yes
7561 67-TOC InRush picked up (67-
TOC InRushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 86 2 Yes
7562 67N-TOC InRush picked up
(67N-TOCInRushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 87 2 Yes
7563 >BLOCK InRush (>BLOCK
InRush)
50/51 Overcur. SP * * * LED BI BO
7564 Ground InRush picked up (Gnd
InRush PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 88 2 Yes
7565 Phase A InRush picked up (Ia
InRush PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 89 2 Yes
7566 Phase B InRush picked up (Ib
InRush PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 90 2 Yes
7567 Phase C InRush picked up (Ic
InRush PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 91 2 Yes
10020 >BLOCK Load Jam Protection
(>BLOCK Load Jam)
48/66/51M Motor SP On
Off
LED BI BO 169 60 1 Yes
10021 Load Jam Protection is
BLOCKED (Load Jam BLOCK.)
48/66/51M Motor OUT On
Off
LED BO 169 61 1 Yes
10022 Load Jam Protection is OFF
(Load Jam OFF)
48/66/51M Motor OUT On
Off
LED BO 169 62 1 Yes
10023 Load Jam Protection is ACTIVE
(Load Jam ACTIVE)
48/66/51M Motor OUT On
Off
LED BO 169 63 1 Yes
10024 Load Jam Protection alarm (Load
Jam alarm)
48/66/51M Motor OUT On
Off
m LED BO 169 64 2 Yes
10025 Load Jam Protection picked up
(Load Jam pickup)
48/66/51M Motor OUT On
Off
m LED BO 169 65 2 Yes
10026 Load Jam Protection TRIP (Load
Jam TRIP)
48/66/51M Motor OUT On
Off
m LED BO 169 66 2 Yes
10027 Startup Duration 1 (Dur.) Mot.Statistics VI
10028 Startup Current 1 (Cur.) Mot.Statistics VI
10029 Startup Voltage 1 (Volt.) Mot.Statistics VI
10030 Total Number of Motor Starts
(Nr.of Mot.Start)
Mot.Statistics VI
10031 Total Motor Running Time (Motor
Run.Time)
Mot.Statistics VI
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
