Siemens SIPROTEC 7SK80 User Manual

Appendix
A.9 Information List
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
466
14143 RTD 4 Temperature stage 2
picked up (RTD 4 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14151 Fail: RTD 5 (broken wire/shorted)
(Fail: RTD 5)
RTD-Box OUT On
Off
**LEDBO
14152 RTD 5 Temperature stage 1
picked up (RTD 5 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14153 RTD 5 Temperature stage 2
picked up (RTD 5 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14161 Fail: RTD 6 (broken wire/shorted)
(Fail: RTD 6)
RTD-Box OUT On
Off
**LEDBO
14162 RTD 6 Temperature stage 1
picked up (RTD 6 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14163 RTD 6 Temperature stage 2
picked up (RTD 6 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14171 Fail: RTD 7 (broken wire/shorted)
(Fail: RTD 7)
RTD-Box OUT On
Off
**LEDBO
14172 RTD 7 Temperature stage 1
picked up (RTD 7 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14173 RTD 7 Temperature stage 2
picked up (RTD 7 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14181 Fail: RTD 8 (broken wire/shorted)
(Fail: RTD 8)
RTD-Box OUT On
Off
**LEDBO
14182 RTD 8 Temperature stage 1
picked up (RTD 8 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14183 RTD 8 Temperature stage 2
picked up (RTD 8 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14191 Fail: RTD 9 (broken wire/shorted)
(Fail: RTD 9)
RTD-Box OUT On
Off
**LEDBO
14192 RTD 9 Temperature stage 1
picked up (RTD 9 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14193 RTD 9 Temperature stage 2
picked up (RTD 9 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14201 Fail: RTD10 (broken wire/short-
ed) (Fail: RTD10)
RTD-Box OUT On
Off
**LEDBO
14202 RTD10 Temperature stage 1
picked up (RTD10 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14203 RTD10 Temperature stage 2
picked up (RTD10 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14211 Fail: RTD11 (broken wire/short-
ed) (Fail: RTD11)
RTD-Box OUT On
Off
**LEDBO
14212 RTD11 Temperature stage 1
picked up (RTD11 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14213 RTD11 Temperature stage 2
picked up (RTD11 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14221 Fail: RTD12 (broken wire/short-
ed) (Fail: RTD12)
RTD-Box OUT On
Off
**LEDBO
14222 RTD12 Temperature stage 1
picked up (RTD12 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14223 RTD12 Temperature stage 2
picked up (RTD12 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
16001 Sum Current Exponentiation Ph
A to Ir^x (ΣI^x A=)
Statistics VI
16002 Sum Current Exponentiation Ph
B to Ir^x (ΣI^x B=)
Statistics VI
16003 Sum Current Exponentiation Ph
C to Ir^x (ΣI^x C=)
Statistics VI
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
