2.1 General
57
7UT613/63x Manual
C53000-G1176-C160-2
If the global data are implausible, the device does not find any meaningful combination
of assignment possibilities. In this case you will find address 230 ASSIGNM. ERROR,
which shows one of the following options:
• No AssigMeasLoc the number of assigned measuring locations is implausible;
• No of sides the number of sides is implausible.
This parameter cannot be changed. It merely informs you about the implausibility of
the global settings. If it appears, you cannot make any further assignments. Recheck
in this case carefully the addresses 211, 212, and 213 and correct the settings.
Only one of the variety of the following listed assignment parameter is possible. But in
the actual case, only one address appears, namely the address which corresponds to
the above mentioned number of sides and assigned measuring locations. The mea-
suring location and side are separated by a comma, e.g. 3M,2S means 3 assigned
measuring locations at 2 sides.
Only the combinations possible for the number of measuring locations and sides
appear as setting options. The measuring locations of the same side are connected
by a „+“ sign; the side sequence by a comma. In the following, all possibilities are ex-
plained.
Address
220 ASSIGNM. 2M,2S appears if 2 assigned measuring locations (address
212) have been selected for 2 sides (address 213). Only one option is possible:
• M1,M2, i.e. the 2 measuring locations are assigned: M1 to side S1, M2 to side S2.
Since no other possibilities exist there are no further options.
Address
221 ASSIGNM. 3M,2S appears if 3 assigned measuring locations (address
212) have been selected for 2 sides (address 213). The following options are possi-
ble:
• M1+M2,M3, i.e. the 3 measuring locations are assigned: M1 and M2 to side S1, M3
to side S2.
• M1,M2+M3, i.e. the 3 measuring locations are assigned: M1 to side S1, M2 and M3
to side S2.
Address
222 ASSIGNM. 3M,3S appears if 3 assigned measuring locations (address
212) have been selected for 3 sides (address 213). Only one option is possible:
• M1,M2,M3, i.e. the 3 measuring locations are assigned: M1 to side S1, M2 to side
S2, M3 to side S3. This corresponds to the examples in figures 2-4 and 2-6, 2-7.
The further assignment possibilities can only occur in 7UT635 since 7UT613 and
7UT633 provide a maximum of 3 three-phase current inputs (cf. table 2-1).
Address
223 ASSIGNM. 4M,2S appears if 4 assigned measuring locations (address
212) have been selected for 2 sides (address 213). The following options are possi-
ble:
• M1+M2,M3+M4, i.e. the 4 measuring locations are assigned: M1 and M2 to side S1,
M3 and M4 to side S2. This corresponds to the example in Figure 2-2 (M5 is not
assigned there).
• M1+M2+M3,M4, i.e. the 4 measuring locations are assigned: M1 and M2 and M3 to
side S1, M4 to side S2.
• M1,M2+M3+M4, i.e. the 4 measuring locations are assigned: M1 to side S1, M2 and
M3 and M4 to side S2.
