Siemens SIPROTEC 7UT613 series User Manual

A Appendix
610
7UT613/63x Manual
C53000-G1176-C160-2
30120 Broken wire IL1 measurement lo-
cation 1 (brk. wire IL1M1)
Supervision OUT ON
OFF
**LEDBO
30121 Broken wire IL2 measurement lo-
cation 1 (brk. wire IL2M1)
Supervision OUT ON
OFF
**LEDBO
30122 Broken wire IL3 measurement lo-
cation 1 (brk. wire IL3M1)
Supervision OUT ON
OFF
**LEDBO
30123 Broken wire IL1 measurement lo-
cation 2 (brk. wire IL1M2)
Supervision OUT ON
OFF
**LEDBO
30124 Broken wire IL2 measurement lo-
cation 2 (brk. wire IL2M2)
Supervision OUT ON
OFF
**LEDBO
30125 Broken wire IL3 measurement lo-
cation 2 (brk. wire IL3M2)
Supervision OUT ON
OFF
**LEDBO
30126 Broken wire IL1 measurement lo-
cation 3 (brk. wire IL1M3)
Supervision OUT ON
OFF
**LEDBO
30127 Broken wire IL2 measurement lo-
cation 3 (brk. wire IL2M3)
Supervision OUT ON
OFF
**LEDBO
30128 Broken wire IL3 measurement lo-
cation 3 (brk. wire IL3M3)
Supervision OUT ON
OFF
**LEDBO
30129 Broken wire IL1 measurement lo-
cation 4 (brk. wire IL1M4)
Supervision OUT ON
OFF
**LEDBO
30130 Broken wire IL2 measurement lo-
cation 4 (brk. wire IL2M4)
Supervision OUT ON
OFF
**LEDBO
30131 Broken wire IL3 measurement lo-
cation 4 (brk. wire IL3M4)
Supervision OUT ON
OFF
**LEDBO
30132 Broken wire IL1 measurement lo-
cation 5 (brk. wire IL1M5)
Supervision OUT ON
OFF
**LEDBO
30133 Broken wire IL2 measurement lo-
cation 5 (brk. wire IL2M5)
Supervision OUT ON
OFF
**LEDBO
30134 Broken wire IL3 measurement lo-
cation 5 (brk. wire IL3M5)
Supervision OUT ON
OFF
**LEDBO
30135 Incons. M1: CBaux open/ curr.
persistent (Incons.CBaux M1)
Supervision OUT ON
OFF
**LEDBO
30136 Incons. M2: CBaux open/ curr.
persistent (Incons.CBaux M2)
Supervision OUT ON
OFF
**LEDBO
30137 Incons. M3: CBaux open/ curr.
persistent (Incons.CBaux M3)
Supervision OUT ON
OFF
**LEDBO
30138 Incons. M4: CBaux open/ curr.
persistent (Incons.CBaux M4)
Supervision OUT ON
OFF
**LEDBO
30139 Incons. M5: CBaux open/ curr.
persistent (Incons.CBaux M5)
Supervision OUT ON
OFF
**LEDBO
30140 Incons. S1: CBaux open/ curr.
persistent (Incons.CBaux S1)
Supervision OUT ON
OFF
**LEDBO
30141 Incons. S2: CBaux open/ curr.
persistent (Incons.CBaux S2)
Supervision OUT ON
OFF
**LEDBO
30142 Incons. S3: CBaux open/ curr.
persistent (Incons.CBaux S3)
Supervision OUT ON
OFF
**LEDBO
30143 Incons. S4: CBaux open/ curr.
persistent (Incons.CBaux S4)
Supervision OUT ON
OFF
**LEDBO
30144 Incons. S5: CBaux open/ curr.
persistent (Incons.CBaux S5)
Supervision OUT ON
OFF
**LEDBO
30145 Failure: disconnect measurment
location (Fail.Disconnect)
Supervision OUT ON
OFF
**LEDBO
30251 Primary fault current IL1 meas.
loc. 1 (IL1M1:)
P.System Data 2 VI * *
30252 Primary fault current IL2 meas.
loc. 1 (IL2M1:)
P.System Data 2 VI * *
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
