Siemens SIPROTEC 7UT613 series User Manual

A.9 Information List
611
7UT613/63x Manual
C53000-G1176-C160-2
30253 Primary fault current IL3 meas.
loc. 1 (IL3M1:)
P.System Data 2 VI * *
30254 Primary fault current IL1 meas.
loc. 2 (IL1M2:)
P.System Data 2 VI * *
30255 Primary fault current IL2 meas.
loc. 2 (IL2M2:)
P.System Data 2 VI * *
30256 Primary fault current IL3 meas.
loc. 2 (IL3M2:)
P.System Data 2 VI * *
30257 Primary fault current IL1 meas.
loc. 3 (IL1M3:)
P.System Data 2 VI * *
30258 Primary fault current IL2 meas.
loc. 3 (IL2M3:)
P.System Data 2 VI * *
30259 Primary fault current IL3 meas.
loc. 3 (IL3M3:)
P.System Data 2 VI * *
30260 Primary fault current IL1 meas.
loc. 4 (IL1M4:)
P.System Data 2 VI * *
30261 Primary fault current IL2 meas.
loc. 4 (IL2M4:)
P.System Data 2 VI * *
30262 Primary fault current IL3 meas.
loc. 4 (IL3M4:)
P.System Data 2 VI * *
30263 Primary fault current IL1 meas.
loc. 5 (IL1M5:)
P.System Data 2 VI * *
30264 Primary fault current IL2 meas.
loc. 5 (IL2M5:)
P.System Data 2 VI * *
30265 Primary fault current IL3 meas.
loc. 5 (IL3M5:)
P.System Data 2 VI * *
30266 Primary fault current IL1 side3
(IL1S3:)
P.System Data 2 VI * *
30267 Primary fault current IL2 side3
(IL2S3:)
P.System Data 2 VI * *
30268 Primary fault current IL3 side3
(IL3S3:)
P.System Data 2 VI * *
30269 Primary fault current IL1 side4
(IL1S4:)
P.System Data 2 VI * *
30270 Primary fault current IL2 side4
(IL2S4:)
P.System Data 2 VI * *
30271 Primary fault current IL3 side4
(IL3S4:)
P.System Data 2 VI * *
30272 Primary fault current IL1 side5
(IL1S5:)
P.System Data 2 VI * *
30273 Primary fault current IL2 side5
(IL2S5:)
P.System Data 2 VI * *
30274 Primary fault current IL3 side5
(IL3S5:)
P.System Data 2 VI * *
30275 Primary fault current I8 (I8:) P.System Data 2 VI * *
30276 Primary fault current I9 (I9:) P.System Data 2 VI * *
30277 Primary fault current I10 (I10:) P.System Data 2 VI * *
30278 Primary fault current I11 (I11:) P.System Data 2 VI * *
30279 Primary fault current I12 (I12:) P.System Data 2 VI * *
30351 >Manual close signal measure-
ment loc. 1 (>ManualClose M1)
P.System Data 2 SP * * * LED BI BO
30352 >Manual close signal measure-
ment loc. 2 (>ManualClose M2)
P.System Data 2 SP * * * LED BI BO
30353 >Manual close signal measure-
ment loc. 3 (>ManualClose M3)
P.System Data 2 SP * * * LED BI BO
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
