Siemens SIRIUS 3RW44 - Data Set 100 - Reading the Device Identification

PROFIBUS DP Communication Module
SIRIUS 3RW44 System Manual
8-60 GWA 4NEB 535 2195-02 DS 04
8.12.14 Data Set 100 - Reading the Device Identification
Table 8-30: Data set 100 - reading the device identification
*) Time stamp: Time of the initialization with the factory settings in the factory
ID No.: Byte
Bit
Value Comment
Preamble
0 Coordination Writing 0x20 via channel C1 (PLC)
Writing 0x30 via channel C2 (PC)
Writing 0x40 via device interface (PC)
1 - 3 Reserved = 0
Device identification (TF)
901 4 - 11 ... Time stamp
*)
902 12 - 31 SIEMENS AG Manufacturer
903 32 - 55 Order number
904 56 0x01 Device family: load feeder
905 57 0x01 Device sub-family: soft starters
906 58 0x01 Device class: e.g. direct on line starter
907 59 0x03 System: SIRIUS 3RW44
908 60 0x46 Function group
909 61 0x00 Reserved = 0
910 62 - 77 Short product description
911 78 - 81 e.g. E001 HW version (byte 0 to byte 3)
912
82 0x00 ID number (byte0) (3RW44)
83 0x00 ID number (byte1) (3RW44)
84 0x80 ID number (byte2) (3RW44)
85 0xDE ID number (byte3) (3RW44)
86 - 87 0x00 Reserved = 0
915 88 - 95 ... Service number
96 0x00 Reserved = 0
97 0x00 Reserved = 0
98 0x00 Reserved = 0
99 0x00 Reserved = 0
