10.3 Technical Data
10.3.1Selection and Ordering Data
Standard circuit Standard circuit
Ambient temperature 40 °C Ambient temperature 50 °C
Rated operating
voltage U
e
Rated operating
current I
e
Rated output of three-phase motors for rated
operating voltage U
e
Rated operating
current I
e
Rated output of three-phase motors for rated
operating voltage U
e
Order No.
V A 230 V / kW 400 V / kW 500 V / kW 690 V / kW A 200 V / HP 230 V / HP 460 V / HP 575 V / HP
200 ... 460
29 5.5 15 — — 26 7.5 7.5 15 — 3RW44 22-@BC@4
36 7.5 18.5 — — 32 10 10 20 — 3RW44 23-@BC@4
47 11 22 — — 42 10 15 25 — 3RW44 24-@BC@4
57 15 30 — — 51 15 15 30 — 3RW44 25-@BC@4
77 18.5 37 — — 68 20 20 50 — 3RW44 26-@BC@4
93 22 45 — — 82 25 25 60 — 3RW44 27-@BC@4
400 ...600
29 — 15 18.5 — 26 — — 15 20 3RW44 22-@BC@5
36 — 18.5 22 — 32 — — 20 25 3RW44 23-@BC@5
47 —2230— 42 ——25303RW44 24-@BC@5
57 — 30 37 — 51 — — 30 40 3RW44 25-@BC@5
77 —3745— 68 ——50503RW44 26-@BC@5
93 — 45 55 — 82 — — 60 75 3RW44 27-@BC@5
400 ... 690
29 — 15 18.5 30 26 — — 15 20 3RW44 22-@BC@6
36 — 18.5 22 37 32 — — 20 25 3RW44 23-@BC@6
47 —22304542 ——25303RW44 24-@BC@6
57 — 30 37 55 51 — — 30 40 3RW44 25-@BC@6
77 —37457568 ——50503RW44 26-@BC@6
93 — 45 55 90 82 — — 60 75 3RW44 27-@BC@6
Order No. extension for connection method
Screw-type terminals
Spring-loaded terminals
200 ... 460
113 30 55 — — 100 30 30 75 — 3RW44 34-@BC@4
134 37 75 — — 117 30 40 75 — 3RW44 35-@BC@4
162 45 90 — — 145 40 50 100 — 3RW44 36-@BC@4
203 55 110 — — 180 50 60 125 — 3RW44 43-@BC@4
250 75 132 — — 215 60 75 150 — 3RW44 44-@BC@4
313 90 160 — — 280 75 100 200 — 3RW44 45-@BC@4
356 110 200 — — 315 100 125 250 — 3RW44 46-@BC@4
432 132 250 — — 385 125 150 300 — 3RW44 47-@BC@4
551 160 315 — — 494 150 200 400 — 3RW44 53-@BC@4
615 200 355 — — 551 150 200 450 — 3RW44 54-@BC@4
693 200 400 — — 615 200 250 500 — 3RW44 55-@BC@4
780 250 450 — — 693 200 250 600 — 3RW44 56-@BC@4
880 250 500 — — 780 250 300 700 — 3RW44 57-@BC@4
970 315 560 — — 850 300 350 750 — 3RW44 58-@BC@4
1076 355 630 — — 885 350 400 850 — 3RW44 65-@BC@4
1214 400 710 — — 1051 400 450 950 — 3RW44 66-@BC@4
400 ... 600
113 — 55 75 — 100 — — 75 75 3RW44 34-@BC@5
134 — 75 90 — 117 — — 75 100 3RW44 35-@BC@5
162 — 90 110 — 145 — — 100 125 3RW44 36-@BC@5
203 — 110 132 — 180 — — 125 150 3RW44 43-@BC@5
250 — 132 160 — 215 — — 150 200 3RW44 44-@BC@5
313 — 160 200 — 280 — — 200 250 3RW44 45-@BC@5
356 — 200 250 — 315 — — 250 300 3RW44 46-@BC@5
432 — 250 315 — 385 — — 300 400 3RW44 47-@BC@5
551 — 315 355 — 494 — — 400 500 3RW44 53-@BC@5
615 — 355 400 — 551 — — 450 600 3RW44 54-@BC@5
693 — 400 500 — 615 — — 500 700 3RW44 55-@BC@5
780 — 450 560 — 693 — — 600 750 3RW44 56-@BC@5
880 — 500 630 — 780 — — 700 850 3RW44 57-@BC@5
970 — 560 710 — 850 — — 750 950 3RW44 58-@BC@5
1076 — 630 800 — 885 — — 850 1100 3RW44 65-@BC@5
1214 — 710 900 — 1051 — — 950 1200 3RW44 66-@BC@5
Order No. extension for connection method
Order No. extension for rated control supply voltage U
s
Screw-type terminals
Spring-loaded terminals
AC 115 V
AC 230 V
1
3
2
6
3
4
