Description

1.5 Device versions

SIRIUS 3RW55 soft starter

Manual, 08/2018, A5E35630887002A/RS-AB/002

Size 1

Size 2

Size 3

Size 4

Rated operational current

Rated power

The stated power ratings apply to a rated operational voltage of U

= 400 V in an inline

circuit.
