Messages and diagnostics
8.3 Warnings and remedial measures of the 3RW55 soft starter
SIRIUS 3RW55 soft starter
176 Manual, 08/2018, A5E35630887002A/RS-AB/002
8.2.3
Overview of LEDs on High Feature 3RW5 HMI
The display of the device LEDs of the 3RW5 HMI High Feature shows the messages of the
following devices:
● 3RW5 soft starter
● 3RW5 communication module (if there is one)
● 3RW5 HMI High Feature
Note
Display of device LEDs.
Please note that the display of the device LEDs of the 3RW5 HMI High Feature does not
have to correlate with the displa
y of the device LEDs of the 3RW5 soft starter.
Status LED
Status
LED
Status of the soft starter
Motor operating state
Lights up
green
Operation The ramp-up time is over, the motor is running,
and the soft starter is in bypass mode.
Flashes
green
Ramp-up or ramp-down time active Motor is ramping up or ramping down.
Reference
You will find more information on soft starter messages in the Chapter "Status and error
displays (Page 175)".
You will find more information on the messages of the 3RW5 communication module in the
manual for the 3RW5 communication module in question.
