4.8 Connecting the control terminals (spring-type terminals)
SIRIUS 3RW55 soft starter
62 Manual, 08/2018, A5E35630887002A/RS-AB/002
4.8
Connecting the control terminals (spring-type terminals)
Requirements
● Observe the conductor cross-sections and tightening torques in the data sheet or on the
front beneath the hinged cover.
● Pay attention to the required tools indicated on the front beneath the hinged cover.
Procedure
DANGER
Hazardous voltage.
Will cause death or serious injury.
Turn off and lock out all power supplying this device before working on this device.
Example circuits
You will find additional information on connecting the control terminals in Chapters Control
circuit connection (Page 207) and Special applications (Page 212).
