4.7 Disconnecting the control current form the screw-type terminals

SIRIUS 3RW55 soft starter

Manual, 08/2018, A5E35630887002A/RS-AB/002

4.7

Disconnecting the control current form the screw-type terminals

Requirements

● Pay attention to the required tools indicated on the front beneath the hinged cover.

Procedure

DANGER

Hazardous voltage.

Will cause death or serious injury.

Turn off and lock out all power supplying this device before working on this device.
