Functions
7.18 3RW5 HMI High Feature
SIRIUS 3RW55 soft starter
Manual, 08/2018, A5E35630887002A/RS-AB/002
171
Parameters
The "Micro SD Card" menu appears after you have inserted a micro SD card into the 3RW5
HMI High Feature.
Action
Description
Load parameter settings to soft starter This menu
item appears if a valid parameterization file is
stored on the micro SD card. The parameterization file
is transferred from the micro SD card to the soft starter.
The following data is transferred:
• Device parameters of the 3RW5 HMI High Feature
• Device parameters of the 3RW55 soft starter
• User management / passwords
Load parameterization onto micro SD card The parameterization file is transferred from the soft
starter to the micro SD card. The following data is
transferred:
• Device parameters of the 3RW5 HMI High Feature
• Device parameters of the 3RW55 soft starter
• User management / passwords
Device change
• Back up the configuration data on
the micro SD card
• Transfer configuration data to soft
starter
When a device is replaced, the configuration can be
transferred to the new device. The following data is
transferred:
• I&M 1 data
• I&M 3 data
• Device parameters of the 3RW5 HMI High Feature
• Device parameters of the 3RW55 soft starter
• Communication parameters
• User management / passwords
Back up the logbooks on the micro SD card The logbooks are backed up on the micro SD card. For
more information, see Chapter Logbooks (Page 187).
Delete micro SD card
The contents of the micro SD card are deleted.
FW update
• Soft starter
• Communication
• HMI
• All devices
This menu item appears if a valid firmware file is stored
on the micro SD card. The 3RW5 HMI High Feature
automatically detects which firmware file the
micro SD card contains:
The firmware update is documented in the device
logbook.
Memory space
• Complete memory
• Free memory
• Used memory
The memory capacity is displayed.
