SDM3055 Series Digital Multimeter User Manual

36 int.siglent.com

Table 2-6 Measurement Characteristics of 4-Wire Resistance

Ranges*

200Ω , 2kΩ , 20kΩ , 200kΩ , 2MΩ , 10MΩ , 100MΩ

Open-circuit Voltage

<8V

Input Protection

(1) 1000V on each range (HI terminal)

(2) 200V on each range (HI Sense, LO Sense)

Configurable Parameters

Range, Rel

NOTE*:

All the ranges enable to obtain 20% value higher than original. Besides, both Manual and Auto

are available for setting every range.

4. Set relative value (Optional operation).

Press [Rel] to open or close Relative math function. When it is open, the reading displayed is a

relative value which comes from the result of actual measurement value subtracts the value that

has been set. (Please refer to “Math Functions” in Chapter 2 to know about the details.)

5. Read measurement result.

Select required measurement rate (reading rate) by pressing [Speed] and read the measurement

result.

6. View history data.

There are four types of way to view historical data: “Number”, “Bar Meter” “Trend Chart” and

“Histogram”.

NOTE:

Please do not put the terminals of the resistance on the conductive plane or in your hand to avoid

error. The bigger of the resistance, the more affection it will be brought.
