Icon Description
Authorisation cross: Remove
Authorisation has been configured,
but not programmed yet.
Authorisation cross: No authorisa-
tion
If none of the previous three crosses
are displayed, there is currently no
authorisation at this position.
Locking devices & keys
Icon Description
Locking device: Locking device
This component is either a locking
device or a locking cylinder.
An additional radio symbol in the
lower left corner indicates that an
online extension is available.
Locking device: SmartRelay
This component is a SmartRelay.
An additional radio symbol in the
lower left corner indicates that an
online extension is available.
Key: Transponder
This component is a transponder.
Key: PIN code keypad
This component is a PIN code
keypad.
An additional radio symbol in the
lower left corner indicates that an
online extension is available.
