ü PIN code keypad already configured; see supplied quick guide
(master
pin and at least one user pin must be configured!)
ü Lock created for PIN code keypad (see
Creating a lock [}18]
or
Creating
a lock with online upgrade [}41]
)
ü Matrix screen open
1. Click on the Add Key icon (next to the SAVE button).
2. Select the type PIN CODE KEYPAD .
3. Specify the lock on which the PinCode keypad is operated.
4. Assign a name for PIN 1
(corresponds to user PIN 1)
, e.g. "Hans Müller".
The white checkbox for PIN 1 is already active.
5. If you want to use a second and third PIN, select the checkboxes. Then
proceed in the same way as for PIN 1.
6. If you want to create another PinCode Keypad, select the checkbox
Create another.
9 With this checkbox you remain in this view after saving and can
immediately create another PIN code keypad.
7. Click on the button SAVE .
9 The PIN code keypad is created.
NOTE
Up to 3 user PINs can be configured directly on the PIN code keypad. These
user PINs must be activated in the web app when the PIN code keypad is
assigned to a locking device.
NOTE
Individual user PINs for an existing PIN code keypad can be changed by
clicking on the corresponding button in the matrix and selecting
EDIT .
5.4 Issue authorisation and save
Authorisations can be issued or withdrawn on the matrix screen.
Authorising key at locking device: Click on the empty field at the
intersection point between the key and locking device to add a cross.
The cross is displayed reduced in size until the new authorisation has
been programmed:
. Once programming is successfully complete, the
cross fills the entire matrix square:
.
Revoking a key's authorisation for a locking device: Click on the empty
field at the intersection point between the key and locking device to
remove the authorisation cross.
MobileKey (Manual)
5. Basic functions
22 / 75
