Sensor data can be displayed on the interface panel LCD, on a remote CRT, or printed on a remote printer. Figure
32 shows a typical TrueAlarm
status report as it might appear on a CRT screen.
Figure 32
Typical TrueAlarm
Status Report Screen
With the proper operator access, a TrueAlarm
Service Report can be generated to list the specific details of each
TrueAlarm
device. Figure 33 shows a typical Service Report screen.
Figure 33
Typical TrueAlarm
Service Report Screen
TIME: 2:40:46 custom title USER: 1
DATE: FRI 4 MAR 94 Port 1 Card 5 A ACCESS: 1
REPORT 3 : TRUEALARM STATUS REPORT
Press PF3 for next screen OR PF4 to return to menus
Zone
Name Custom Label
Sensi-
tivity Device Status
Almost
Dirty
M1-1 ANALOG PHOTO 2.5 NORMAL- CLEAN ROOM
M1-2 ANALOG ION 1.3 NORMAL- CLEAN ROOM
M1-3 ANALOG PHOTO 2.5 NORMAL- MAIN LOBBY
M1-4 ANALOG PHOTO 2.5 NORMAL- CONFERENCE ROOM 1
M1-10 HEAT DETECTOR 135F NORMAL- GARAGE
M1-11 ANALOG PHOTO 2.5 NORMAL- KITCHEN *YES*
*YES*
TIME: 2:53:27 custom title USER: 1
DATE: FRI 4 MAR 94 Port 1 Card 5 A ACCESS: 1
REPORT 4 : TRUEALARM STATUS REPORT
Press PF3 for next screen OR PF4 to return to menus
Custom Label
Alarm
at:
CLEAN ROOM DEV 1
Avg
val
Avg Current/
% alarm
Peak/
% alarm
State
2.5/135 67 68/ 1% 68/ 1% NOR
CLEAN ROOM ION DET DEV 2 1.3/209 94 97/ 2% 101/ 1% NOR
MAIN LOBBY DEV 3 2.5/157 89 89/ 0% 89/ 0% NOR
CONFERENCE ROOM 1 DEV 4 2.5/161 93 93/ 0% 93/ 0% NOR
GARAGE DEV 10 HEAT DETECTOR 135F/253 — 66/ 69F 63/ 67F NOR
KITCHEN DEV 11 2.5/159 91 92/ 1% 92/ 1% NOR
