Simplex 4100U Application Guide

vi
Before you start using the Smoke Management Application Guide, it is important to understand the
conventions used in this publication.
The following conventions are used to identify special names or text.
• Italic type indicates titles of publications, such as the Smoke Management Application Guide.
• Text enclosed in quotation marks indicates important terms or titles of chapters and sections
of the manual, such as “How to Use this Publication.”
• Bulleted lists, such as this one, provide you with information. They are also used to indicate
alternatives in numbered procedural steps.
• Numbered lists indicate procedures with steps that you must carry out sequentially.
About This Guide
Conventions Used

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
