Simplex 4100U Application Guide

4-3
The following table lists the UUKL addressable monitor/control devices for the 4100U or 4100ES
system.
Table 4-1. UUKL Addressable Monitor/Control Device List for 4100U/4100ES
Model Description IDNet™ MAPNET II
®
See Doc #
4090-9001
Supervised IAM, single address, single point; IDNet and
4100U/4100ES provide “T” sense (current limited
monitoring); MAPNET II and 4100U/4100ES provide simple
N.O. Class B monitoring.
574-331
4090-9002
Relay IAM, single address, single point; Form “C” with relay
status tracking.
–– 574-184
4090-9101 Class B monitor ZAM.
574-183
4090-9106 Class A monitor ZAM.
4090-9118*
Relay IAM with T sense input, single address, dual point,
relay and input.
–– 574-874
4090-9119*
Relay IAM with unsupervised input, single address,
dual point, relay and input.
–– 574-875
4090-9120* Six point module; four T sense inputs, 2 relays; one address. –– 574-876
4100-7401 24 Point I/O Graphic Module. –– ––
841-802
S4100-0005
4100-7402 64/64 LED/Switch Controller. –– ––
841-802
S4100-0005
4100-7403 32 Point LED Module –– ––
841-802
S4100-0005
4100-7404 32 Point Switch Module. –– ––
841-802
S4100-0005
4602-7101
Graphic I/O, RCU/SCU (Remote Control Unit/Status Control
Unit, selectable operation).
–– –– ––
Table 4-2. MAPNET II UUKL Addressable Monitor/Control Device List for 4100U/4100ES
Model Description IDNet™ MAPNET II
®
See Doc #
2190-9153 Class A Monitor ZAM, surface mount. ––
574-668
2190-9154 Class A Monitor ZAM, flush mount. ––
2190-9155 Class B Monitor ZAM, surface mount. ––
2190-9156 Class B Monitor ZAM, flush mount. ––
2190-9159 Class A Signal ZAM, surface mount. ––
575-279
2190-9160 Class A Signal ZAM, flush mount. ––
2190-9161 Class B Signal ZAM, surface mount. ––
2190-9162 Class B Signal ZAM, flush mount. ––
2190-9163 Control Relay ZAM, surface mount. ––
2190-9164 Control Relay ZAM, flush mount. ––
2190-9173*
2-Point I/O Module supervised input and relay output;
two sequential addresses.
––
574-995
* Devices designed specifically for Smoke Control Applications.
Note: These are common smoke control system components and do not include other commonly used fire detection
components such as pull stations, heat detectors, and initiation and notification appliances.
Continued on next page
General Smoke Control Interconnections, Continued
UUKL Addressable
Monitor/Control
Devices for 4100U
and 4100ES

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
