Simrad AP50 User Manual

Software Set-up Procedure
20221032B 131
Set-up item
(abbrev. name)
Equipment
connected
(name)
Connected to terminal
(use one available from list)
Assign hardware
port to set-up item
(* = default setting)
FLUX1 Not connected – – – –
RFC35R Connection to RobNet ROBNET*
Junction unit: HS+, HS– J50-HS
J50, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
CI300X, Analog terminal CI300X
FLUX2 Not connected – – – – *
RFC35R Connection to RobNet ROBNET
Junction unit: HS+, HS– J50-HS
J50, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
CI300X, Analog terminal CI300X
WIND Not connected – – – – *
J50, Main PCB NMEA I/P RX1+,RX1– J50-1
J50, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
DEPTH Not connected – – – – *
J50, Main PCB NMEA I/P RX1+,RX1– J50-1
J50, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
LOG Not connected – – – – *
J50, Main PCB NMEA I/P RX1+,RX1– J50-1
J50, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
GI51 Pulse log terminal GI-LOG
J50 = All junction unit models
