Simrad AP50 Autopilot
46 20221032B
2.15 Instrument Screens and Menu
A number of instrument screens are available under each mode
screen if the required NMEA 0183 sentences are provided (see
page 68). Activate the instrument screen by pressing the
INFO
(INFO) button.
Note ! The Instrument screens are also available on locked units.
The left-hand side of the display will show the following
information, depending on the mode:
340.7
Gyro1
341°
340.7
Gyro1
CTS
341°
A
w
340.7
Gyro1
CTS
341°
Aw
340.7
Gyro1
CTS
.02NM
340.7
Gyro1
N
w
.02NM
340.7
Gyro1
.02NM
N
w
340.7
Gyro1
STANDBY.
Heading.
Heading input
source.
AUTO AUTO-WORK AUTO-WORK
w/thruster
Set course
Heading/Heading input source.
NAV NAV-WORK NAV-WORK
w/thruster
Cross Track error
Heading/Heading input source.
Move through the available instrument screens by repeatedly
pressing the
INFO
(INFO) button. The right-hand side of the
display will show the following instrument screens:
02
RUDDER
090
270
000
340
SP
Gyro1
LOG
COG
DEPTH 199.5m
04.9
274°
kt
COG 274°T SOG 2.40kt
BPW 272°T
SIMRAD
WP
XTE
DST
GPS1
32.2NM0.023NM
Main Speed/Course/Depth* Motorway
(Speed from LOG,
SOG or MAN)
* The depth reading is referenced to the transducer, not the keel.
