Simrad AP50 User Manual

Advanced Settings
20221032B 159
SETTINGS
Displayed parameter Boat type (Default settings) Own boat
Dockside Menu
Displacement Planing Waterjet Autotune Manual
Master Operation No No No
Boat length 0-50 feet 0-50 feet 0-50 feet
Drive unit voltage 12V 12V 12V
Rudder limit 10° 10° 10°
Rudder deadband AUTO AUTO AUTO
Thruster - - - - - - - - - - - -
Settings Menu
W Init rudder Actual Actual Actual
W Autotrim Yes Yes Yes
Autotrim 48 sec 40 sec 40 sec
Course adj. 1° 1° 1°
Compass diff. 10° 10° 10°
Off heading lim 10° 10° 10°
Drive engage Bypass/clutch
Drive type - - - - - - - - - - - -
Drive out 50% 50% 50%
Prop. gain 18 18 18
Seastate AUTO AUTO AUTO
Rudder 0.50 0.30 0.30
Counter rudder 0.90 0.90 0.90
W Seastate AUTO AUTO AUTO
W Rudder 0.75 0.45 0.45
W Count Rudder 1.40 1.40 1.40
W Rudder limit 10° 10° 10°
Cruising speed 15kt 15kt 15kt
Speed response 0.00 0.00 0.00
Transition speed OFF OFF OFF
Nav gain 3.5 3.5 3.5
Minimum rudder 0.0° 0.0° 0.0°
Turn mode ROT ROT ROT
Rate Of Turn 240°/min 240°/min 240°/min
W Rate Of Turn 240°/min 240°/min 240°/min
Added stop time 0s 0s 0s
Init NAV Firm Firm Firm
Turn gain 38 38 38
W Turn gain 38 38 38
Rate sensitivity 15 15 15
Thruster inhibit 10 kt 10 kt 10 kt
Thruster sens 1°/5° 1°/5° 1°/5°
Continuous 1.0 1.0 1.0 Thruster
gain
Adaptive on/ off 2.0 2.0 2.0
Minimum thrust 00 00 00
Thruster hyst 00 00 00
Thruster drive Continuous Continuous Continuous
Response delay 1.0 sec 1.0 sec 1.0 sec
