ADVANCED SETTINGS
20221537 / D 71
Main
Category
Sub
Category
Parameter/description
Default
value
Range
A-2
2.1.o Bearing offset A (°)
Offset value included in the “master bearing” and used
for correction of fixed error (°). If the master compass
not can be mounted parallel to the vessel’s fore-after
line, this parameter is used to compensate for a small
mounting error.
0.0 0.0 – 359.9
2.2.O Bearing offset B (°)
1
Value for general bearing error correction to enter to
master compass bearing. It is used to correct the bearing
if the bearing for some reason deviates from correct
heading.
This value is cleared when it passes the zero-cross pin
or when power is switched OFF.
0.0 0.0 – 359.9
2.3.h Zero-cross bearing (°)
Absolute bearing set for MCU board when zero-cross
pin was passed during start-up sequence (last azimuth
operation) and normal running operation.
Zero-cross bearing can be set in this menu, but is
normally set up be measuring position (angle) of the
zero-cross pin in the master com
ass by the test mode
A.
345.3 0.0 – 359.9
2.4.E Zero-cross error allowance (°)
Zero-cross alarm limit. The compass will generate a
zero cross alarm when the difference between the zero-
cross bearing and the relative bearing exceeds this zero
cross value.
This value should be set every time the zero-cross pin is
detected.
2.0 0.0 – 5.0
2.5.y Year
Used for setting current year.
- 2000 - 2099
2.6.N Month and Day
Used for setting current month and date.
- -
2.7.t Hour and Minute
Used for setting current hour and minute.
- -
2.8.d Total days of operation
This value should be reset after the installation is
completed.
- -
1
This value is cleared at the time of zero crossing pin passage and a power
supply OFF.
