Sipromac 600A - Page 22

MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
± 0.5
± 0. 5
INCH
± 0.004"
± 0.020"
± 0.020"
N.T.S.
NO.
005D0324
SBU
1
M-I
600A
MACHINE ASSEMBLY
13-12-11
005D0324
3/5
-PUMP + AIR REGULATOR INSTALLATION-
1
2
3
4
5
6
7
8
9
10
11
12
HOLES TO USE
100M³: 2-5-10-12
165M³: 1-4-7-9
255M³: 2-5-8-11
305M³: 2-5-8-11
A
DETAIL A
B
DETAIL B
13 AIR REGULATOR OPTION
44
36 T&B ONLY
3 SOFT AIR (165M³ & +)
4 SILENCER + SOFT AIR (165M³ & +)
2 SILENCER (165M³ & +)
11 165M³ PUMP
8 305M³ PUMP
12 255M³ PUMP
10 100M³ PUMP
6 SOFT AIR (100M³)
7 SILENCER + SOFT AIR (100M³)
5 SILENCER (100M³)
