Sipromac 600A - MC-40 Control Board

MACHINE
PART
ITEM
MAT.
CNC
3D DWG BY
2D DWG BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
± 0.5
± 0. 5
INCH
± 0.004"
± 0.020"
± 0.020"
N.T.S.
NO.
005C0583
SBU
1
M
VACUUM
MC-40 CONTROL BOARD
15-02-23
005C0583
LET. MODIFICATION DATE INT.
A
SS INSERT
15-02-23 SBU
-MC-40 OPTION-
SBU
15-02-23
1
2
3
5
6
7
8
9
ITEM PART # DESCRIPTION QT.
1 001B6920 CONTROL PANEL MC-40 1
2 033-0038 MC-40 SENSOR VACUUM 1
3 051-0092 SCREW #4-40 x 1 1/4" FLAT SLT S/S 4
4 051-01081 SCREW 8-32 X 1/2'' TRUSS SLOT SS 6
5 051-0540 NUT #4-40 HEX S/S 8
6 051-0713 WASHER #4 FLAT S/S 4
7 051-0715 WASHER #4 LOCK SS 4
8 058-0120 CPVC SPACER 0.120" x 1/4" x 5/8" 4
9 179-0004 NITRILE 1/2'' X 1/8'' AUTOCOLLANT X
1210mm long
1
4
5
