Sipromac 600A - Shackle Assy

MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
± 0.5
± 0. 5
INCH
± 0.004"
± 0.020"
± 0.020"
N.T.S.
NO.
004A3937
J.G.
LISTE
M-(M)
VACUUM
SHACKLE ASS'Y
12-11-06
004A3937
LET. MODIFICATION DATE INT.
QTY
MACHINE
4
600A
ITEM PART # DESCRIPTION QT.
1 004A3935 SHACKLE PRE-ASS'Y 1
2 001A6269 SHACKLE PLATE 1
3 056-0118 COTTER PIN 3/32" x 1" S/S 1
2
1
3
