Sipromac 600A - Seal Bar Assy W;Support (Eco)

005F0561
Y.F.
4
M-I
600A & 620A
SEAL BAR ASS'Y W/SUPPORT (ECO)
14-02-19
005F0561
MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
± 0.5
± 0. 5
INCH
± 0.004"
± 0.020"
± 0.020"
N.T.S.
NO.
LET.
MODIFICATION
DATE INT.
G
005D0153 WAS 005C0153
13-11-06 SBU
H
600A ADDED
14-05-27 SBU
QTY
MACHINE
4
620A
-BAG CUT OPTION-
-END VIEW-
1
ITEM PART # DESCRIPTION QT.
5 001-0269 SEAL BAR GUIDE 2
3 001-1591 EXTERIOR BELLOWS COVER 1
4 001-1958 INTERIOR BELLOWS COVER 1
2 002A4191 SEAL BAR SUPPORT (ECO) 1
1 005F0419 SEAL BAR PRE-ASS'Y 1
8 051-0230 HEX BOLT 1/4-20 x 1 1/4" SS 5
7 051-0250 BOLT ¼"-20nc. X 1½" S/S 4
10 051-0251 CAP. HEX. SKT BOLT 1/4"-20 NC. x 1 1/2" 4
9 051-0581 NUT 1/4"-20 NYLON LOCK S/S 9
6 051-0740 WASHER 1/4" FLAT S/S 8
2
5
7
8
6
4
3
10
9
3
4
600A
