Sipromac 600A - 8 Cover Assembly

005B0453
SBU
1
M-(M)-I
600A
8" COVER ASSEMBLY
14-02-04
005B0453
MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
± 0.5
± 0. 5
INCH
± 0.004"
± 0.020"
± 0.020"
N.T.S.
NO.
LET.
MODIFICATION
DATE INT.
C
004B0236 WAS 004A0236
14-02-04 SBU
ITEM PART # DESCRIPTION QT.
1 004B0236 8" COVER PRE-ASS'Y 1
2 179-0020 NEOPRENE SPONGE 1/2" x 14.5' 1
1
2 UTILISER PERMATEX RUBBER ADHESIVE 169-0010 POUR COLLERUSE PERMATEX RUBBER ADHESIVE 169-0010 TO GLUE
POSITION JOINT HERE
POSITIONNER LE JOINT ICI
