Sipromac 600A - Spring Insert Assembly

MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
± 0.5
± 0. 5
INCH
± 0.004"
± 0.020"
± 0.020"
N.T.S.
NO.
004A3968
J.G.
LISTE
M-(M)
600A & 620A
SPRING INSERT ASSEMBLY
13-01-15
004A3968
LET. MODIFICATION DATE INT.
A
AJOUTER 620A
13-01-23 J.G.
QTY
MACHINE
4
620A
4
600A
2
ITEM PART # DESCRIPTION QT.
1 002A3989 SPRING ADJUSTMENT ROD 1
2 051-0600 NUT 5/16" -18 S/S 2
3 002B3940 SPRING INSERT 1
3
1
2
