005C0421
SBU
2
M-(M)-I
600A & 620A
UPPER SEAL BAR ASS'Y W/SUPPORT
13-09-25
005C0421
MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
±
0.5
±
0.
5
INCH
± 0.004"
±
0.020"
±
0.020"
N.T.S.
NO.
LET.
MODIFICATION
DATE
INT.
H
AJOUT TEFLON HOLDER
13-09-25
SBU
J
600A ADDED
14-05-27
SBU
A
DETAIL A
1
12
3
11
10
ITEM PART # DESCRIPTION QT.
1 002A0536 UPPER SEAL BAR SUPPORT 1
2 002C0401 UPPER SEAL BAR 1
3 051-0232 SCREW 1/4-20x 1-1/4"SKT CAP SS 8
4 001-2666 ELEMENT BINDER 2
5 051-0146 SCREW 10-24 X 1" PAN PHIL S/S 8
6 051-0572 NUT #10-24 NYLON LOCK S/S 8
7 051-0104 SCREW 8-32 x 3/8" RND PHIL S/S 2
8 051-0550 NUT #8-32 SS 4
9 027-0400 CONNECTOR ADAPTOR 2
10 179-0003 SILICONE 2mm x 15mm ADHESIVE 733mm
(0.73)
1
11 176-0220 TEFLON TAPE,PRESS.SENSITIVE 2" 733mm
(0.089)
1
12 039-0220 BI-ACTIVE SEALING ELEMENT (6mm) 776mm
(0.078)
1
13 056-1400 1/4"SET SCREW BANDING BUCKLE S/S 2
14 077-0095 SPRING C 0360-059-1250 S/S 2
15 176-0203 TEFLON TAPE, 5MIL UNCOATED ZONE
733mm (0.089)
1
16 001A6583 UPPER TEFLON HOLDER 2
2
6
13 INSTALL AGAINST NOTCH OF ITM #4INSTALLER CONTRE ENCOCHE DE L'ITEM #4
4 ALLOW TO MOVE FREELYPERMETTRE DE BOUGER LIBREMENT
13
-TOP & BOTTOM SEALING OPTION-
5
9
8
8
7
CE COTÉ DE LA BARRE DOIT ÊTRE ÉGAL
AU SUPPORT
THIS SIDE OF SEAL BAR TO FIT FLUSH
WITH SUPPORT
14
15
16
6
16
5
