Section 4 – Troubleshooting Information Electrical System
1. Loose or broken wire 15 from shifter connector J47
pin 7 to chassis harness 31 pin connector J31 pin
2
Check continuity. Replace if defective.
2. Loose or broken wire 15 from 31 pin connector
P31 pin 2 to engine harness connector J13 pin 5.
Check continuity. Replace if defective.
3. Loose or broken wire 15 from connector P13 pin 5
to reverse diode D15.
Check continuity. Replace if defective.
4. Loose or broken wire 15A from reverse diode to
reverse solenoid Connector P9 pin 1.
Check continuity. Replace if defective.
5. Defective reverse diode D15.
Check for continuity with positive lead on
connector P13 pin 5 and negative lead on reverse
solenoid connector P9 pin 1. Replace if defective.
6. Loose or broken wire 51 from reverse solenoid
connector P9 pin 2 to chassis harness P13 pin 2.
Check continuity. Replace if defective.
7. Defective reverse solenoid. Replace solenoid.
8. Defective transmission shifter. Replace shifter
4.2-8 No 1st Speed Range
1. Loose or broken wire 216 from shifter connector
J47 pin 2 to chassis harness 31 pin connector J31
pin 4
Check continuity. Replace if defective.
2. Loose or broken wire 216 from 31 pin connector
P31 pin 3 to engine harness connector J13 pin 4.
Check continuity. Replace if defective.
3. Loose or broken wire 216 from connector P13 pin
3 to 1st solenoid connector P11 pin 1.
Check continuity. Replace if defective.
4. Loose or broken wire 00 from 1st solenoid
connector P11 pin 2 to ground.
Check continuity. Replace if defective.
5. Defective 1st solenoid. Replace solenoid.
6. Defective transmission shifter. Replace shifter
4.2-9 No 2nd Speed Range
1. Loose or broken wire 215 from shifter connector
J47 pin 3 to chassis harness 31 pin connector J31
pin 5
Check continuity. Replace if defective.
2. Loose or broken wire 215 from 31 pin connector
P31 pin 5 to engine harness connector J13 pin 4.
Check continuity. Replace if defective.
