Skyjack SJ1044 TH - Electrical Components Parts List

44
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Section 3 – System Component Identification and Schematics Electrical Components Parts List
3.3 Electrical Components Parts List
Index
No.
Skyjack
Part No.
Qty. Description
60CR 9-921734 1 RELAY, Power Relay
11CR 9-165029 1 RELAY, Glow Plug
56ACR 9-156200 1 RELAY, Fuel Pump
403ACR 9-931298 1 RELAY, Positive Air Shutoff
19CR 9-931298 1 RELAY, Boom Up
222CR 9-931298 1 RELAY, Frame Level Enable
224CR 9-931298 1 RELAY, Carriage Tilt Enable
5JCR 9-931298 1 RELAY, Brake Lamp
77CR 9-931298 1 RELAY, Engine Running
212CR 9-931298 1 RELAY, Boom Angle
65CR 9-931298 1 RELAY, Frame Level Disable
28CR 9-931298 1 RELAY, Boom Raise Disable
28LCR 9-931298 1 RELAY, Frame Left Enable
28RCR 9-931298 1 RELAY, Frame Right Enable
05CR 9-931298 1 RELAY, Park Brake Release
255CR 9-931298 1 RELAY, Rear Wiper
258CR 9-931298 1 RELAY, Front Wiper
258ACR 9-931298 1 RELAY, Top Wiper
250ACR 9-931298 1 RELAY, Left Turn Signal
251ACR 9-931298 1 RELAY, Right Turn Signal
223ACR 9-931298 1 RELAY, RAS Restric Mode Enable
220CR 9-931298 1 RELAY, RAS Drive/Brake
F1 9-156203 1 FUSE, Ignition/ Power (10A)
F2 9-156203 1 FUSE, Transmission/Back-up Alar/ Park Brake (10A)
F3 9-156203 1 FUSE, Steer Select/Gauge/Transmission Temp (10A)
F4 9-156203 1 FUSE, Frame/Carriage Enable (10A)
F5 9-156203 1 FUSE, Rear Axle Lock (10A)
F6 9-156202 1 FUSE, Auxilliary Hydraulics (5A)
F7 9-156203 1 FUSE, Horn/Beacon Option (10A)
F8 9-156204 1 FUSE, Power port (15A)
F9 9-156202 1 FUSE, Rear wiper (5A)
F10 9-156203 1 FUSE, Outriggers (10A)
F11 9-156203 1 FUSE, Work lights (10A)
F12 9-156204 1 FUSE, Road lights (15A)
F13 9-156202 1 FUSE, Turn/Hazard/Brake lights (5A)
F14 9-156203 1 FUSE, Boom lights (10A)
F15 9-156203 1 FUSE, Front & Top Wiper (10A)
F16 - - Not used.
