45
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Electrical Components Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Qty. Description
F17 9-156202 1 FUSE, Fan/Interior Light (5A)
F18 9-156164 1 FUSE, Blower motor (30A)
F20 9-156203 1 FUSE, Heater Valve & A/C (10A)
F19 9-156203 1 FUSE, Frame Level Interlock (10A)
F21 9-156164 1 FUSE, SCR Control (30A)
F22 9-156204 1 FUSE, After SCR CAT (15A)
F23 9-156202 1 FUSE, Prior SCR CAT (5A)
F24 9-156204 1 FUSE, DEF Level (5A)
F25 9-156164 1 FUSE, ECM (30A)
F26 9-121504 1 FUSE, Fuel Pump (20A)
F27 9-165031 1 FUSE, Glow Plug (100A)
SW1 9-926721 1 SWITCH, Ignition
SW2 9-191454 1 SWITCH, Park brake
SW3 - - Not used.
SW4 9-191457 1 SWITCH, Steer mode
SW5 9-196995 1 SWITCH, Frame level (Joystick)
SW6 9-405339 1 SWITCH, Horn switch (button)
SW7 9-196995 1 SWITCH, Carriage Tilt (Joystick)
SW8 9-191680 1 SWITCH, Fan
SW9 9-191455 1 SWITCH, positive shutoff
SW10 9-191455 1 SWITCH, boom lights
SW11 9-191457 1 SWITCH, work lights+
SW12 9-191457 1 SWITCH, turn signal
SW13 9-191658 1 SWITCH, Interior light
SW14 9-191459 1 SWITCH, rear washer/wiper
SW15 9-197031 1 SWITCH, Auxiliary Extend
SW16 9-197031 1 SWITCH, Auxiliary Retract
SW17 - - Not used.
SW18 9-191491 1 SWITCH, A/C
SW19 9-191457 1 SWITCH, Road lights
SW20 - - Not used.
SW21 9-191458 1 SWITCH, LH outrigger
SW22 9-191458 1 SWITCH, RH Outrigger
SW23 9-191455 1 SWITCH, Hazard lights
SW24 9-191459 1 SWITCH, Washer/wiper front/top
D05J 9-102921 1 DIODE, Console harness
D26B 9-102921 1 DIODE, Console harness
D60 9-102921 1 DIODE, Console harness
D252 9-102921 1 DIODE, Console harness
D252-1 9-102921 1 DIODE, Console harness
D252A-1 9-102921 1 DIODE, Console harness
D252A-2 9-102921 1 DIODE, Console harness
