Skyjack SJ1044 TH - Page 46

46
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Section 3 – System Component Identification and Schematics Electrical Components Parts List
Index
No.
Skyjack
Part No.
Qty. Description
D221 9-102921 1 DIODE, Chassis Harness
D15 9-102921 1 DIODE, Engine Harness
D250 9-102921 1 DIODE, Road light Harness
D251 9-102921 1 DIODE, Road light Harness
D60-1 9-102921 1 DIODE, Console harness
D15A 9-102921 1 DIODE, Console harness
D16 9-102921 1 DIODE, Console harness
- 9-190547 2 SENSOR, Inductive proxi - mm
- 9-166700 2 SENSOR, Pressure
2H-19A 9-159821 1 COIL, #8
2H-57 9-159821 1 COIL, #8
2H-221 9-159821 1 COIL, #8
2H-28 9-159821 1 COIL, #8
2H-28A 9-159821 1 COIL, #8
4H-223 9-159821 1 COIL, #8
4H-223-1 9-159821 1 COIL, #8
4H-47 9-159821 1 COIL, #8
4H-47-1 9-159821 1 COIL, #8
3H-26 9-168057 1 COIL, #10
4H-217 9-168057 1 COIL, #10
4H-218 9-168057 1 COIL, #10
