Skyjack SJ1044 TH - Hydraulic Components Parts List

47
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Hydraulic Components Parts List Section 3 – System Component Identification and Schematics
3.4 Hydraulic Components Parts List
Index
No.
Skyjack
Part No.
Qty. Description
ACC1 9-400947 1 ACCUMULATOR, Diaphragm (if equipped)
ACC2 9-400947 1 ACCUMULATOR, Diaphragm (if equipped)
C1 9-190027 1 CYLINDER, Front steer
C1 9-205013 1 CYLINDER, Front steer - SJ1256 THS
C2 9-190028 1 CYLINDER, Rear steer
C2 9-205032 1 CYLINDER, Rear steer - SJ1256 THS
C3 9-190038 1 CYLINDER, Lift - 150B
C3 9-205058 1 CYLINDER, Lift - SJ1256 THS
C4 9-190038 1 CYLINDER, Lift - 150B
C4 9-205058 1 CYLINDER, Lift - SJ1256 THS
C5 9-190045 1 CYLINDER, Extend - 115B
C5 9-205061 1 CYLINDER, Extend 130B - TH1056 - SJ1256 THS
C6 9-190040 1 CYLINDER, Tilt comp - 120B
C6 9-205789 1 CYLINDER, Tilt comp 120B - SJ1256 THS
C7 9-190043 1 CYLINDER, Fork tilt - 120B
C7 9-205788 1 CYLINDER, Fork tilt - 120B - SJ1256 THS
C8 9-191832 1 CYLINDER, RAS
C9 9-190041 1 CYLINDER, Frame level - 115B
C9 9-205063 1 CYLINDER, Frame level - 115B - SJ1256 THS
C10 9-191123 1 CYLINDER, TH Outriggers
C10 9-205064 1 CYLINDER, TH Outriggers - SJ1256 THS
C11 9-191123 1 CYLINDER, TH Outriggers
C11 9-205064 1 CYLINDER, TH Outriggers - SJ1256 THS
C12 9-190025 1 CYLINDER, Front Axle
C12 9-205013 1 CYLINDER, Front Axle - SJ1256 THS
CB1 9-199472 1 VALVE, Counter-balance - 4200PSI
CB1 9-206179 1 VALVE, Counter-balance -230/120 - SJ1256 THS
CB2 9-191812 1 VALVE, Counter-balance - 1800PSI
CB2 9-206180 1 VALVE, Counter-balance -150 - SJ1256 THS
CB3 9-191813 1 VALVE, Counter-balance - 4000PSI - SJ1056 TH/THS
CB3 9-199473 1 VALVE, Counter-balance - 3900PSI - SJ1044 TH/THS
CB3 9-206182 1 VALVE, Counter-balance -310/70 - SJ1256 THS
CB4 9-191814 1 VALVE, Counter-balance - 4000PSI
CB4 9-206233 1 VALVE, Counter-balance - 290 - SJ1256 THS
CB5 9-191815 1 VALVE, Counter-balance - 6000PSI
CB6 9-191816 1 VALVE, Counter-balance - 3000PSI
CB6 9-206181 1 VALVE, Counter-balance -350 - SJ1256 THS
CB7 9-191816 1 VALVE, Counter-balance - 3000PSI
CB7 9-206181 1 VALVE, Counter-balance -350 - SJ1256 THS
CB8 9-149366 1 VALVE, Counter-balance - 4000PSI
CB8 9-206229 1 VALVE, Counter-balance -225 - SJ1256 THS
CB9 9-149366 1 VALVE, Counter-balance - 4000PSI
CB9 9-206181 1 VALVE, Counter-balance -350 - SJ1256 THS
CB10 9-149366 1 VALVE, Counter-balance - 4000PSI
