48
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Section 3 – System Component Identification and Schematics Hydraulic Components Parts List
Index
No.
Skyjack
Part No.
Qty. Description
CB10 9-206181 1 VALVE, Counter-balance -350 - SJ1256 THS
CB11 9-149366 1 VALVE, Counter-balance - 4000PSI
CB11 9-206229 1 VALVE, Counter-balance -225 - SJ1256 THS
CB12 9-191816 1 VALVE, Counter-balance -3700 PSI - SJ1256 THS
CB13 9-191816 1 VALVE, Counter-balance -3700 PSI - SJ1256 THS
CV1 9-166066 1 VALVE, Check
CV1 9-171412 1 VALVE, Check
CV2 9-166066 1 VALVE, Check
CV2 9-171412 1 VALVE, Check - SJ1256 THS
CV3 9-166066 1 VALVE, Check
CV3 9-171412 1 VALVE, Check - SJ1256 THS
CV4 9-166066 1 VALVE, Check
CV4 9-171412 1 VALVE, Check - SJ1256 THS
CV5 9-166066 1 VALVE, Check
CV5 9-171412 1 VALVE, Check - SJ1256 THS
CV6 9-166066 1 VALVE, Check
CV6 9-171412 1 VALVE, Check - SJ1256 THS
CV7 9-166066 1 VALVE, Check
CV7 9-171412 1 VALVE, Check - SJ1256 THS
CV8 9-166066 1 VALVE, Check
CV8 9-171412 1 VALVE, Check - SJ1256 THS
CV9 9-166066 1 VALVE, Check
CV9 9-171412 1 VALVE, Check - SJ1256 THS
CV10 9-166066 1 VALVE, Check
CV10 9-171412 1 VALVE, Check - SJ1256 THS
CV11 9-191805 1 VALVE, Check
CV11 9-206177 1 VALVE, Check - SJ1256 THS
CV12 9-191805 1 VALVE, Check
CV12 9-206177 1 VALVE, Check - SJ1256 THS
CV13 9-191806 1 VALVE, Check disc
CV14 9-199470 1 VALVE, Check
CV15 9-199471 1 VALVE, Check
CV16 9-171412 1 VALVE, Check
CV17 9-171412 1 VALVE, Check
CV18 9-191806 1 VALVE, Check
CV19 9-191806 1 VALVE, Check
EC1 9-191799 1 PRESSURE COMPENSATOR
EC1 9-206188 1 PRESSURE COMPENSATOR - SJ1256 THS
F1 9-157907 1 FILTER ELEMENT, Hydraulic spin-on
F2 9-191484 1 FILLER BREATHER, 1PSI
JS1 9-190356 1 JOYSTICK, Hydraulic
JS1 9-922265 1 JOYSTICK, Hydraulic
MB1 9-169031 1 MANIFOLD, Main
MB1 9-205190 1 MANIFOLD, Main - SJ1256 THS
MB2 9-169033 1 MANIFOLD, Auxiliary
MB2 9-205202 1 MANIFOLD, Auxiliary - SJ1256 THS
MB3 9-190357 1 MANIFOLD, Reserve brake
MB4 9-198734 1 MANIFOLD, RAS
