Skyjack SJ1044 TH - Pressure Settings

33
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
2.5 Pressure SettingsTable
SJ1044 TH/THS - SJ1056 TH/THS - SJ1256 THS
System Component Test Port Pressure Value 10K Pressure Value 12K
Pilot Oil Pressure GP2 400 PSI 400 PSI
Tilt Comp./Carriage Tilt Port Relief - 3300 PSI 3900 PSI
System
Standby Pressure (Load Sense) GP1 450 PSI 450 PSI
Maximum Pressure GP1 3250 PSI 3900 PSI
Steering
Maximum RV2 2600 PSI 2600 PSI
Brakes
Service Brake PS2 900 PSI 900 PSI
1339AA
NOTE
All pressures to be checked with engine running
at idle unless specified otherwise.
NOTE
Service brake pressure is variable. The value
provided above is the maximum nominal value.
