Service Brake Actuator (Brake Pedal) Ports Identification Section 3 – System Component Identification and Schematics
3.7 Service Brake Actuator (Brake Pedal) Ports Identification
Port T to Port DR1
on Main Manifold
Port P to Port SB
on Main Manifold
Port P to Port A1 on
optional Reserve
Brake Manifold
Port P to Port A1
on optional Reserve
Brake Manifold
M191582-SM
