Skyjack SJ1044 TH - Glow Plug Harness & Wiring Diagram

A B C D E F G H
V
Z
Y
X
W
66
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
100
11B03 03
RELAY CONNECTION DETAIL
TERM 30 - 11B (RED)
TERM 85 - 11A (BLACK)
TERM 86 - 11 (BLACK)
TERM 87 - 11C (RED)
11B
11C
11
11A
TO 87
TO 30
TO 85
11A-18 BK
11C-8 RD
11B-8 RD
TO 86
(+)
J5
2
3
11C-18 RD
11A-18 BK
11-18 BK
4
11-18 BK
1
11B-8 RD
2 1
P1
11C-10 RD
11C-10 RD
J5
P1
CONNECTOR J5
PIN 1 - 11C BLACK
PIN 2 - 11A BLACK
PIN 3 - 11 RED
PIN 4 - PLUGGED
CONNECTOR P1
SOCKET 1 - 11C RED (10GA)
SOCKET 2 - 11C RED (10GA)
3.18 Glow Plug Harness & Wiring Diagram
M191468AB-S1
