SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Hydraulic Components Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Qty. Description
MB5 9-169034 1 MANIFOLD, Outrigger
MB5 9-205191 1 MANIFOLD, Outrigger - SJ1256 THS
MB6 9-206115 1 MANIFOLD, RV4-1 - SJ1256 THS
MB7 9-213232 1 MANIFOLD, Premium Joystick (Option)
OR1 9-191807 1 PLUG, Orifice
OR2 9-191808 1 PLUG, Orifice
OR3 9-191809 1 PLUG, Orifice
OR3 9-206178 1 PLUG, Orifice - SJ1256 THS
OR4 9-191829 1 PLUG, Orifice
OR4 9-199033 1 PLUG, Orifice - SJ1256 THS
OR5 9-199474 1 PLUG, Orifice
OR5 9-191809 1 PLUG, Orifice - SJ1256 THS
OR6 9-197300 1 PLUG, Orifice
OR7 9-199032 1 PLUG, Orifice
OR8 9-199475 1 PLUG, Orifice
OR9 9-199475 1 PLUG, Orifice - SJ1256 THS
OR10 9-199475 1 PLUG, Orifice - SJ1256 THS
OR11 9-206224 1 PLUG, Orifice - SJ1256 THS
OR12 9-206224 1 PLUG, Orifice - SJ1256 THS
OSM1 9-406450 1 MOTOR, Steering wheel
P1 9-190263 1 PUMP, Hydraulic
P1 9-205221 1 PUMP, Hydraulic - SJ1256 THS
PR1 9-191798 1 SWITCH, Pressure reducing/relieving
PR2 9-220518 1 SWITCH, Pressure reducing/relieving - SJ1256 THS
PS1 9-191810 1 SWITCH, Pressure 450 PSI
PS2 9-927724 1 SWITCH, Pressure brake light
PS3 9-191800 1 SWITCH, Pressure 350 PSI - SJ1256 THS
RV1 9-191802 1 VALVE, Relief
RV2 238579 1 VALVE, Relief
RV3 9-221887 1 VALVE, Relief anti-cavitation
RV4 9-191804 1 VALVE, Relief anti-cavitation
RV4-1 9-206093 1 VALVE, Relief anti-cavitation - SJ1256 THS
RV5 9-238580 1 VALVE, Relief
RV6 9-238571 1 VALVE, Relief
RV7 9-238582 1 VALVE, Relief
SV1 9-197301 1 VALVE, Shuttle
SW 9-197304 1 SWITCH, Pressure 1500 PSI
V1 9-191794 1 VALVE, Proportional-pilot operated
V1 9-206190 1 VALVE, Proportional-pilot operated - SJ1256 THS
V2 9-191793 1 VALVE, Proportional, pilot operated
V2 9-206191 1 VALVE, Proportional-pilot operated - SJ1256 THS
V3 9-191794 1 VALVE, Proportional, pilot operated
V3 9-206190 1 VALVE, Proportional-pilot operated - SJ1256 THS
V4 9-191793 1 VALVE, Proportional, pilot operated
V4 9-206191 1 VALVE, Proportional-pilot operated - SJ1256 THS
V5 9-191795 1 VALVE, Solenoid 4W3P
V6 9-191796 1 VALVE, Solenoid 4W2P
