SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Section 3 – System Component Identification and Schematics Hydraulic Components Parts List
Index
No.
Skyjack
Part No.
Qty. Description
V7 9-191796 1 VALVE, Solenoid 4W2P
V8 9-191796 1 VALVE, Solenoid 4W2P
V9 9-191796 1 VALVE, Solenoid 4W2P
V10 9-171796 1 VALVE, Solenoid cartridge
V11 9-102626 1 VALVE, Solenoid cartridge spool
V12 9-926370 1 VALVE, Brake
V13 9-191801 1 VALVE, Piloted 2W N.O.
V13 9-206192 1 VALVE, PILOTED 2-WAY SPOOL. - SJ1256 THS
V14 9-191797 1 VALVE, Solenoid 5W3P
V14 9-205813 1 VALVE PROPORTIONAL AUX. 12K - SJ1256 THS
V15 9-166038 1 VALVE, 2 way, normally closed spool
V15 9-206194 1 VALVE, SOLENOID CARTRIDGE, 2-WAY - SJ1256 THS
V16 9-102626 1 VALVE, Solenoid cartridge spool
V17 9-102626 1 VALVE, Solenoid cartridge spool
V18 9-197302 1 VALVE, Pressure unloading
V19 9-197303 1 VALVE, Low flow 2 way, normally closed
V20 9-168056 1 VALVE, 2W2P - SJ1256 THS
V21 9-199466 1 VALVE, SOLENOID POPPET 2W N.C. - SJ1256 THS
V22 9-168056 1 VALVE, 2W2P - SJ1256 THS
V23 9-199467 1 VALVE, SOLENOID POPPET 2W N.C. - SJ1256 THS
V24 9-199467 1 VALVE, SOLENOID POPPET 2W N.C. - SJ1256 THS
V25 9-205813 1 VALVE PROPORTIONAL AUX. 12K - SJ1256 THS
V26 9-205813 1 VALVE PROPORTIONAL AUX. 12K - SJ1256 THS
V27 9-213997 COIL, DROP IN -EHPR98-T33 12VDC (Option)
V28 9-213997 COIL, DROP IN -EHPR98-T33 12VDC (Option)`
