158
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Section 5 – Procedures 1000 Hour or Annual Routine Maintenance
RAS System Logic Truth Table
Service
Brake Fully
Depressed
Park
Brake
Driving
Frame
Leveling
Boom up
>=40
Axle
Free Limited Locked
0 0 0 0 0 1 0 0
0 0 0 0 1 0 0 1
0 0 0 1 0 1 0 0
0 0 0 1 1 0 1 0
0 0 1 0 0 1 0 0
0 0 1 0 1 0 1 0
0 0 1 1 0 1 0 0
0 0 1 1 1 0 1 0
0 1 0 0 0 1 0 0
0 1 0 0 1 0 0 1
0 1 0 1 0 1 0 0
0 1 0 1 1 0 1 0
0 1 1 0 0 1 0 0
0 1 1 0 1 0 0 1
0 1 1 1 0 1 0 0
0 1 1 1 1 0 1 0
1 0 0 0 0 1 0 0
1 0 0 0 1 0 0 1
1 0 0 1 0 1 0 0
1 0 0 1 1 0 1 0
1 0 1 0 0 1 0 0
1 0 1 0 1 0 0 1
1 0 1 1 0 1 0 0
1 0 1 1 1 0 1 0
1 1 0 0 0 1 0 0
1 1 0 0 1 0 0 1
1 1 0 1 0 1 0 0
1 1 0 1 1 0 1 0
1 1 1 0 0 1 0 0
1 1 1 0 1 0 0 1
1 1 1 1 0 1 0 0
1 1 1 1 1 0 1 0
