18
SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Section 1 – Scheduled Maintenance Scheduled Maintenance Inspections
▪
Drive Axles - A
Ensure drive axles are properly secured, there are
no loose or missing parts, all fittings and hoses are
properly tightened and there is no evidence of oil
leakage.
▪
Steer Cylinder - A
Ensure steer cylinders are properly secured, there
are no loose or missing parts, all fittings and hoses
are properly tightened and there is no evidence of
hydraulic oil leakage.
▪
Planetary Wheel Ends - C
Check the planetary wheel ends oil level and add as
required. Ensure there is no evidence of oil leakage.
▪
Axle Differential - C
Check the axle differential oil level and add as required.
Ensure there is no evidence of oil leakage.
▪
Battery - A
Proper battery condition is essential to good engine
performance and operational safety. Improper fluid
levels or damaged cables and connections can result in
engine component damage and hazardous conditions..
WARNING
Explosion hazard. Keep flames and sparks away.
Do not smoke near batteries.
WARNING
Battery acid is extremely corrosive - Wear proper
eye and facial protection as well as appropriate
protective clothing. If contact occurs, immediately
flush with cold water and seek medical attention.
1. Check battery case for damage.
2. Clean battery terminals and cable ends
thoroughly with a terminal cleaning tool or wire
brush.
3. Ensure all battery connections are tight.
4. If applicable, check battery fluid level. If plates are
not covered by at least 1/2” (13 mm) of solution,
add distilled or demineralized water.
5. Replace battery if damaged or incapable of
holding a lasting charge.
WARNING
Use original or manufacturer-approved parts and
components for the telehandler.
Battery
Front Axle
Assembly
