SJ1044 TH, SJ1044 THS, SJ1056 TH, SJ1056 THS, SJ1256 THS
230790ABA
Section 5 – Procedures Electronic Tilt Switch Setup Procedure
Logic Truth Table
INPUT
Boom Proxy
Switch
(Wire 221)
(Pin 4)
OUTPUTS
Lamp
(Wire 28C)
(Pin 1)
Frame Level
>4° Left
Frame Level
>4° Right
Frame Level
Right
(Wire 28R)
(Pin 7)
Frame Level
Left
(Wire 28L)
(Pin 6)
Boom UP
Enable
(Wire 28)
(Pin 5)
0 0 0 1 1 1 0
0 0 1 1 1 1 0
0 1 0 1 0 0 1
0 1 1 1 1 1 0
1 0 0 0 1 0 1
1 0 1 1 1 1 0
1 1 0 0 0 0 FLASH
1 1 1 0 0 0 FLASH
4°
4°
0 = Switch Open
1 = Switch
Closed to 12V
0 = Output Open
1 = output 12V
0 = Output Open
1 = output 12V
0 = Output Open
1 = output 12V
0 = Output Open
1 = output 12V
