Skyjack SJ3219 Service Manual

121
SJ3215, SJ3219
212508ADA
Section 5 – Procedures Base
E-0-3-2
CAN Heartbeat Lost
▪
An error was detected with the CAN heartbeat
communications with a registered node being guarded.
▪
Check the networked CANbus device(s) for correct
functioning.
▪
This alarm does not display or get logged on the
charger but does appear on the CAN bus via an
emergency message.
E-0-3-6
Battery temperature sensor is missing or
shorted
▪
Check sensor connections.
▪
The charger behavior when this fault occurs can be
configured. OEMs may contact Delta-Q Technologies for
more information.
▪
This error automatically clears once the condition has
been corrected.
E-0-3-8
Fan will not turn
(Fan-equipped models only)
▪
Check fan connections.
▪
Check to make sure the fan turns freely and is not
obstructed.
▪
This error automatically clears once the condition has
been corrected.
E-0-4-0
Fan voltage pulled low
(Fan-equipped models only)
▪
Check to make sure the fan turns freely.
E-0-4-5 Battery disconnected
▪
Battery disconnected
▪
Reconnect the battery or check the wiring
E-0-4-6 Invalid PDO Length
▪
Check to make sure all PDOs are valid length.
▪
This error automatically clears once the condition has
been corrected
E-0-4-7 Platform overvoltage alarm
▪
A battery or some other source has been connected to
the charger that exceeds the hardware’s design limits.

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
