153
Section 5 – Procedures Skycoded Module
Fault Code List (Continued)
Fault Code Description
F44:LOW PRESSURE
During static (loaded or empty) calibration, the lift cylinder pressure is out of range (below 0.4V or
above 4.6V).
F48:BAD PRESSURE
At the start of calibration, the pressure sensor is out of range (output must be between 0.3V and
4.8V at all times)
F52:NOT
CALIBRATED!
Something happened to cause calibration to fail – it is recommended to check all sensor wiring for
loose connections, then repeat calibration.
FINISHED!
This display occurs when all calibrations (dynamic, loaded up, loaded down, empty up, empty
down) have been completed, and the CALDATE has been entered.
Be sure to press <ESC> on the display module to exit calibration, before attempting to use the
machine.
GO UP MORE!
During calibration, the operator needs to close the UP or DOWN switch as required to lift or lower
the platform – if the switch is closed in the wrong direction, no fault occurs but the machine does
not move! This display clarifies the error.
GO DOWN MORE!
PLEASE WAIT
During calibration, the Control Module CM1 sometimes delays while waiting for sensor values to
stabilize – this display indicates why nothing appears to be happening.
Non-applicable fault codes
There are additional fault codes that may show up on the Skycoded display panel that does not affect your
machine. If you see the following fault codes, calibrate the load 5.4-8 Calibrate Load Procedure and level
5.4-7 Calibrate Level Procedure of your machine again. If the fault codes continue, contact the Skyjack service
department.
Non-applicable Fault Codes
F12:TOO MANY F19:HIGH ELEV.CLOSE F42:LOW PRESSURE IGNORING
F14:BAD HEIGHT1 F24:TOO MANY F43:HIGH PRESSURE
F15:CHECK ELEV F30:BAD HEIGHTS F45:HIGH PRESSURE
F16:LOW ELEV.OPEN F34:REJECT CURVE F46:CHECK ELEV
F17:HIGH ELEV.OPEN
F40:REJECT DELTA
DOWN @
F47:CHECK ELEV
F18:LOW ELEV.CLOSE
F40:REJECT DELTA
UP @
F49:TOO FEW
