Section 2 – Maintenance Tables and Diagrams Torque Specifications
2.11 Torque SpecificationsTable
Base Torque (lb-ft) Torque (Nm)
Directional Valve Mounting Bolts 2.3-2.7 lb-ft (28-32 lb-in) 3.2 -3 .6 Nm
Front Wheel Castle Nut 150* lb-ft 203* Nm
Hydraulic Motor Mounting Bolts 85 lb-ft 115 Nm
Rear Wheel Castle Nut - Pin Brakes Finger tighten until snug*
Rear Wheel Castle Nut - Wet Brakes 150* lb-ft 203* Nm
Wheel Brake Mounting Bolts 85 lb-ft 115 Nm
*See section 5 for the full torque procedure.
Cartridge Coils
Valve Size 8 38 58 10 12 16 All coil sizes
Torque (lb-ft) max 20 20 20 25 35 50 4 to 5
Torque (lb-in) max 240 240 240 300 420 600 48 to 60
Torque (Nm) max 27.12 27.12 27.12 33.9 47.46 67.8 5.42 to 6.78
SAE Plugs
Port Size 2 4 5 6 8 10 12 16
Torque (lb-ft) max 3 10 15 15 25 25 30 35
Torque (lb-in) max 36 120 180 180 300 300 360 420
Torque (Nm) max 4.07 13.56 20.34 20.34 33.9 33.9 40.68 47.46
Newton-meter = Nm Pound-foot = lb-ft Pound-inch = lb-in
Additional Torque Specifications may be found in Section 5.
