Floor Loading Pressure Section 2 – Maintenance Tables and Diagrams
2.10 Floor Loading PressureTable
* Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
** LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the floor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath the
chassis. This has been calculated by dividing the MEWP weight by the overall floor area occupied by the MEWP (on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above.
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
Model
Weights Pressures
MEWP weight
Max weight per
wheel
LCP** OFL**
kg lb kg lb kPa psi kPa psf
3215
ANSI/CSA
min* 1148 2531 290 640 872 126.5 7.9 164
max* 1420 3131 490 1080 1106 160.4 9.7 202
3219
ANSI/CSA
min* 1476 3255 370 816 961 139.4 10.1 210.9
max* 1703 3755 608 1340 1134 164.5 11.7 244.4
3215
CE
min* 1148 - 290 - 872 - 7.9 -
max* 1420 - 490 - 1106 - 9.7 -
3219
CE
min* 1476 - 370 - 961 - 10.1 -
max* 1703 - 608 - 1134 - 11.7 -
3215
AS
min* 1148 - 290 - 872 - 7.9 -
max* 1420 - 490 - 1106 - 9.7 -
3219
AS
min* 1476 - 370 - 961 - 10.1 -
max* 1703 - 608 - 1134 - 11.7 -
3215
KC
min* 1148 - 290 - 872 - 7.9 -
max* 1420 - 490 - 1106 - 9.7 -
3219
KC
min* 1476 - 370 - 961 - 10.1 -
max* 1703 - 608 - 1134 - 11.7 -
* Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
** LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the floor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath the
chassis. This has been calculated by dividing the MEWP weight by the overall floor area occupied by the MEWP (on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above.
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
Model
Weights Pressures
MEWP weight
Max weight per
wheel
LCP** OFL**
kg lb kg lb kPa psi kPa psf
3215
ANSI/CSA
min* 1148 2531 290 640 670 97 7.9 164
max* 1420 3131 567 1250 1093 159 9.7 203
3219
ANSI/CSA
min* 1476 3255 370 815 797 116 10.1 210.9
max* 1703 3755 608 1340 1159 168 11.7 244.4
3215
CE
min* 1148 - 290 - 670 - 7.9 -
max* 1420 - 567 - 1093 - 9.7 -
3219
CE
min* 1476 - 370 - 797 - 10.1 -
max* 1703 - 608 - 1159 - 11.7 -
3215
AS
min* 1148 - 290 - 670 - 7.9 -
max* 1420 - 567 - 1093 - 9.7 -
3219
AS
min* 1476 - 370 - 797 - 10.1 -
max* 1703 - 608 - 1159 - 11.7 -
3215
KC
min* 1148 - 290 - 670 - 7.9 -
max* 1420 - 567 - 1093 - 9.7 -
3219
KC
min* 1476 - 370 - 797 - 10.1 -
max* 1703 - 608 - 1159 - 11.7 -
